Lens

0.4 alpha. Lens is early and shared so people can start playing with it, not as a finished release. Expect rough edges, patches that misbehave, and outright bugs. Loupe is a little language that lets you combine things in lots of ways, so testing every combination is more than I can do alone. Releasing early spreads the debugging across more hands. Please try it, report what you find, and share what you make.

Lens is a program card for the Music Thing Workshop System Computer. It turns the card into a small programmable synth voice or effect: a generative voice, a sequencer, a quantiser, a delay, a Turing machine, a drum kit, whatever you wire up. You write patches in Loupe, a small parens-and-S-expressions language. The compiler turns a patch into a flat snapshot the card runs at 48 kHz.

A patch speaks CV, gates and audio at the six jacks, so the card plays well with the rest of the Workshop System (or any rack, if you run the Computer standalone).

Try it in the browser: grsr.github.io/lens/web (Chrome or Edge, edit a patch and send it to the card over WebMIDI).

A taste

A four-note minor arpeggio that steps once per beat. The voice comes out three ways at once: pitch as v/oct on cv-out-1, a trigger on pulse-out-1, and a sine you can hear directly on audio-out-1.

(patch
  (def master (clock :tempo (knob :x)))
  (def melody (tape '(C3 Eb3 G3 Bb3)))

  (def voice  (step melody))
  (<- (cv-out :1)    (v-oct voice))
  (<- (pulse-out :1) (trig))
  (<- (audio-out :1) (sine voice)))

Knob X sets the tempo. step reads one cell of the tape per clock tick, trig is a trigger pulse on each beat, v-oct turns a MIDI note into a pitch voltage. Every word is documented in docs/loupe.md.

Use it

The web editor is the easiest way in, and the one most people will want. Open it in Chrome or Edge (WebMIDI is needed), connect, pick an example from the dropdown, edit, and send it to the card. It can also save the patch into the card’s flash so it survives a power cycle.

Editing is live. Tick live and every good compile is sent to the card as you type. A same-shape edit (changing a number) keeps the running patch going with no glitch, and you can quantise the swap to the next beat or bar. Keys: Cmd/Ctrl-Enter sends, Cmd/Ctrl-S saves to the card, Cmd/Ctrl-. hushes, Cmd/Ctrl-Shift-Z reverts.

For development and scripted flashing there is a Node CLI:

npm install
node cli/cli.js write patches/turing-machine.loupe          # send a patch
node cli/cli.js write patches/turing-machine.loupe --save   # send and save to flash
node cli/cli.js ping                                         # handshake

node cli/cli.js --help lists the rest. Holding the Z-switch down for a few seconds also saves whatever patch is currently running into flash.

Example patches

The patches in patches/ are starting points, not a survey of the language. Each opens with a few comment lines saying what it does, what the knobs control, and what to patch where. Try hello.loupe (one sine, the knob picks the pitch) and turing-machine.loupe (a note loop that slowly rewrites itself), then browse the folder for the rest. The patches/utility-pair/ subfolder holds small fn library files (low-pass gate, wavefolder, sample-and-hold, slew, and more), a homage to Chris Johnson’s Utility-Pair card and a demo of the (use) style.

You can also play the card live over MIDI: plug a USB MIDI keyboard straight into the card’s USB-C port, or send notes from a computer. It reads notes, velocity, CC and clock, and can send them too, so it works as a voice, a CV/gate converter, or a sequencer driving an external synth. The midi-*.loupe patches cover both directions.

Lens leans into the generative and feedback-driven side of modular, but it doesn’t have to be used that way. It can just be a kick drum, an oscillator, a filter, or any other single voice in your rack.

Repo layout

compiler/   Loupe source -> snapshot pipeline (pure JavaScript)
runtime/    the C runtime, hardware shell (main.cpp), and snapshot decoder
cli/        dev CLI and sysex wire protocol
web/        the web editor (the primary user interface)
tools/      build helpers and lookup-table generators
patches/    example patches
docs/       this documentation
prelude.loupe   the standard library (every builtin and its kwargs)
CMakeLists.txt, pico_sdk_import.cmake, LICENSE, package.json

Build from source

The repo ships a ready-built lens.uf2, and releases attach that committed binary rather than recompiling. To build it yourself you need the Raspberry Pi pico-sdk; it is built and tested with pico-sdk 2.1.1 and arm-gcc 14.2:

cmake -B build
cmake --build build -j

A fresh lens.uf2 lands at the repo root. Flash it the same way you flash any program card: with the module connected over USB, the card mounts as a USB drive called RPI-RP2; copy lens.uf2 onto it.

Loading DX7 voice banks

The dx op plays Yamaha DX7 FM voices, read from banks baked into the firmware. Lens ships no banks of its own: the DX7 voice data is copyrighted, so you supply your own .syx files and rebuild.

1. Get one or more 32-voice DX7 .syx bank files (the standard 4104-byte bulk dump, or a headerless 4096-byte body). Many circulate online under varying licences, so check before you redistribute anything you build.

2. Point tools/gen-dx7banks.js at them by editing its BANKS list:

   const BANKS = [
     { name: 'mybank',  path: 'banks/Bank.syx' },
     { name: 'another', path: 'banks/Other.syx' },
   ];


3. Generate the (gitignored) header and rebuild, then flash the fresh lens.uf2 as above:

   node tools/gen-dx7banks.js
   cmake --build build -j


4. Select voices in a patch by bank and preset:

   (dx :bank 0 :preset 10 :gate g :note 60)   ; voice 10 of the first bank


   :bank is the position in the BANKS list (0, 1, 2, …) and :preset is the voice 0..31 within it. :pitch sets the note, :gate triggers it, and :decay and :tone shape the envelope length and FM brightness. The sysex header and checksum are stripped for you, so any 32-voice .syx works.

Dig in

• docs/loupe.md: the Loupe language guide.
• docs/developer_guide.md: the compiler, the runtime, what runs where, and how to build and modify it.

Acknowledgements

Lens stands on a pile of other people’s work:

• Chris Johnson for ComputerCard.h, the C++ library that talks to the card’s hardware, for the band-limited sawtooth used in the runtime, and for the Utility-Pair card the patches/utility-pair/ folder is a homage to.
• Vincent Maurer for the ADC self-heal pattern inside ComputerCard.h (from his Grains card), and for the reverb, chorus, flanger and compressor kernels, adapted from his Flare fork of Lens.
• Émilie Gillet and Mutable Instruments for Plaits, whose percussion voices inspired the kick, snare and hat.
• Tom Whitwell and Music Thing Modular for the Workshop System and the Computer card this runs on.
• Raspberry Pi for the pico-sdk.

A lot of the hairier parts of the compiler and runtime were written with Claude Code. The human assistant did his best to follow along, takes full responsibility for the bugs, and admits he isn’t 100% sure how some of it works.

This is a hobby project, so replies may be slow. If something breaks, please open an issue with the patch text and what you expected. The card fails amusingly more than dangerously, so it’s usually safe to just try things. A PR with a fix is as welcome as an issue.
